Contact resistance tester 100A HYHL-III

Contact resistance tester output DC 100A current to test the contact resistance
It is designed according to IEC62271.
The main application of the tester is measurement of circuit breaker contact resistance.
All the test results of the tester could be print by the micro-printer which is integrated in the tester.
Also all the test results saved in the tester could be upload to PC computer and then convert to MS WORD document.

1. Measurement range: 0-1999.9 μΩ

2. Resolution:0.1 μΩ

3. Test current: DC 100A

4. Maximum error< 0.5 %RDG+0.05%FS

5. Display mode: LCD

6. Save no more than 100 groups of data

7. RS232 computer interface

8. Rated power supply:AC220V

9. Size: 340 × 280 × 210mm3

10. Environment temperature:-10 ℃~+40 ℃ Relative humidity<80%

Contact Resistance Tester 100A Images
